MOXA TCF-142-S-SC Serial to Fiber Converter

Introduction

The TCF-142 media converters are equipped with a multiple interface circuit that can handle RS-232 or RS-422/485 serial interfaces and multimode or single-mode fiber. TCF-142 converters are used to extend serial transmission up to 5 km (TCF-142-M with multi-mode fiber) or up to 40 km (TCF-142-S with single-mode fiber). The TCF-142 converters can be configured to convert either RS-232 signals, or RS-422/485 signals, but not both at the same time.

You can also find the TCF-142-M-SCTCF-142-S-ST and TCF-142-M-ST models in the TCF-142 Series.


Certifications




Features


  • 1 x RS-232 and 1 x RS-422/485 ports,1 x 100Mbps F(x) single-mode port with SC connector
  • 12 to 48 VDC input power
  • Metal body
  • 0 to 60°C operating temperature
converter : Converter specifications
Data transfer speed 0.05Kbps to 921.6Kbps
Maximum data transmission distance 40Km on the fiber
Minimum output power converter -5dBm
Sensitivity to receiving information -25dBm
Wavelength 1310nm
converter : Power Requirements
Maximum power consumption -
Power Consumption (Output Adapter) 12V DC, 0.14A
Power Input Plugin ( Redundant ) No
converter : Standards and protocols
Point-to-point topology Half-duplex or full-duplex
Ring topology Half-duplex
RS-232 Signals Tx, Rx, GND
RS-422 Signals TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w Signals Data+, Data-, GND
converter : Interface
10/100Mb RJ45 (Megabit) Ports No
100Mb Fiber optic single mode (Megabit) Ports Yes : 1 SC Port
10/100/1000Mb (Gigabit) POE Ports No
100Mb Fiber optic multi mode (Megabit) Ports No
10/100/1000Mb RJ45 (Gigabit) Ports No
1000Mb SFP Fiber optic (Gigabit) Ports No
100Mb SFP Fiber optic (Megabit) Ports No
Number of 10/100Mb PoE port No
USB No
DSL No
Serial port Yes : 1 RS-232/422/485 Port
Other ports No
converter : General
Fan / Fanless -
MTBF 780,480 hour
Require cable diameter 8.3/125μm, 8.7/125μm, 9/125μm, 10/125μm
converter : Physical Characteristics
Dimensions 90x100x22mm
Housing Metal
Installation Desktop converter and Din-rail and wall mount
Isolation No
Operating Temperature 0 to 60 ° C
Operation Humidity -
Operation Humidity 5% to %95 non-condensing
Protection against excessive consumption Yes : 1.1A
Protection against reverse flow Yes
Standards and Certifications Safety: UL 60950-1; EMC: CE, FCC; EMI : FCC Part 15 Subpart B Class B, EN 55022 Class B; EMS : EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 2, EN 61000-4-4 (EFT) Level 2, EN 61000-4-5 (Surge) Level 2, EN 61000-4-6 (CS) Level 2, EN 61000-4-8 (SFMF) Level 1; Green Product : RoHS, CRoHS, WEEE
Storage Temperature -40 to 85 ° C
Weight 0.32Kg
converter : LED Indicators
LED Per Port Yes
Power Yes
converter : Package Checklist
Hardware installation guide Yes
Power adapter No
Power cable No
