MOXA ANT-WDB-PNF-1518 WLAN Antenna

Introduction

The ANT-PNF-1518 is a lightweight compact dual-band high-gain indoor panel antenna with a gain of up to 18 dBi. A wide operating temperature range of -40 to 80°C, IP65-rated housing, and pole-mounting support make it suitable for outdoor use.


Features


  • Dual-band 2.4 GHz and 5 GHz
  • 15 dBi at 2.4 GHz or 18 dBi at 5 GHz
  • panel antenna
  • High-gain antenna to enhance performance
  • Waterproof N-type connector
  • Lightweight
  • Compact form factor
  • Pole-mounting support
  • Housing provides IP65 protection
  • -40 to 80°C operating temperature
Antenna : Antenna Characteristics
Frequency 2.4 to 2.5, 5.1 to 5.9 GHz
Antenna Type Directional, Panel
Antenna Gain 15/18 dBi
Connector N-type (female)
Impedance 50 ohms
Polarization Linear
Antenna : Physical Characteristics
Weight 1,020 g (2.25 lb)
Operating Temperature -40 to 80°C (-40 to 176°F)
Storage Temperature -40 to 80°C (-40 to 176°F)
Ambient Relative Humidity 5 to 95% (30°C, non-condensing)
